CC404B

Bearing Set - Cam

Описание

With wide center bearings. Engines with 1.868" cam journals.

Характеристики

year

82-82

model

Camaro

notes

With wide center bearings.

Spec 1 Sizes

N/A

Spec 1 Width

0.625"

Spec 2 Sizes

N/A

Spec 2 Width

0.720"

Spec 3 Sizes

N/A

Spec 3 Width

0.625"

Spec 1 Position

Spec 2 Position

2-3

Spec 3 Position

Spec 1 Shell P/N

Spec 2 Shell P/N

96A

Spec 3 Shell P/N

Spec 1 Housing Bore

2.0091-2.0100"

Spec 2 Housing Bore

1.9988-2.0002"

Spec 3 Housing Bore

2.0091-2.0100"

Spec 1 Oil Clearance

0.0011-0.0047"

Spec 2 Oil Clearance

0.0011-0.0051"

Spec 3 Oil Clearance

0.0011-0.0047"

Spec 1 Shaft Diameter

1.8677-1.8697"

Spec 1 Wall Thickness

0.0691"

Spec 2 Shaft Diameter

1.8677-1.8697"

Spec 2 Wall Thickness

0.0640"

Spec 3 Shaft Diameter

1.8677-1.8697"

Spec 3 Wall Thickness

0.0691"

Кросс-замены

ACL

4C1102S

King

CS428BB

ACL #2

4C1102S-00

Clemex

SH1102S

King #2

CS429BB

Dura-Bond

CH-18

Fed. Mogul

1492M

Beck Arnley

015-0766

Dura-Bond #2

CH-18A

Mahle Clevite

SH-1364S

Двигатели

Двигатель

Бренды

2.8L / 173 OHV V6 12V "B,R" Chev. 89.00mm Bore 82-93

GM, CHEVROLET

2.8L / 173 OHV V6 12V Chev. 3.504" Bore 84-86

JEEP

2.8L / 173 OHV V6 12V Chev. 89.00mm Bore 80-89

2.8L / 2835 OHV V6 12V "R" GM 89.00mm Bore 89-91

ISUZU

3.1L / 189 OHV V6 12V "D" Chev. 89.00mm Bore 90-95

GM, CHEVROLET

3.1L / 189 OHV V6 12V "J,M,T,W" Chev. 89.00mm Bore 88-05

3.1L / 189 OHV V6 12V "V" Chev. Turbo 89.00mm Bore 89-90

3.1L / 3137 OHV V6 12V "Z" GM 89.00mm Bore 91-94

ISUZU

3.4L / 207 OHV V6 12V "E,F" Chev. 92.00mm Bore 96-09

GM, CHEVROLET

3.4L / 207 OHV V6 12V "E,S" Chev. 92.00mm Bore 93-05

3.5L / 214 OHV V6 12V "8" GM 94.00mm Bore 04-06

3.5L / 214 OHV V6 12V "L" GM 94.00mm Bore 05-07

GM, CHEVROLET

AM173T-CH | 2.8L / 173 OHV V6 12V Chev. 3.504" Bore 84-86

JEEP

GM173C-CH | 2.8L / 173 OHV V6 12V Chev. 89.00mm Bore 80-89

BUICK, CHEVROLET, OLDSMOBILE, PONTIAC, CADILLAC

GM173T-CH | 2.8L / 173 OHV V6 12V "B,R" Chev. 89.00mm Bore 82-93

CHEVROLET, GMC

GM189C-CH | 3.1L / 189 OHV V6 12V "J,M,T,W" Chev. 89.00mm Bore 88-05

BUICK, CHEVROLET, PONTIAC, OLDSMOBILE

GM189CA-CH | 3.1L / 189 OHV V6 12V "V" Chev. Turbo 89.00mm Bore 89-90

PONTIAC

GM189T-CH | 3.1L / 189 OHV V6 12V "D" Chev. 89.00mm Bore 90-95

CHEVROLET, PONTIAC, OLDSMOBILE

GM207CB-CH | 3.4L / 207 OHV V6 12V "E,S" Chev. 92.00mm Bore 93-05

CHEVROLET, PONTIAC, OLDSMOBILE

GM207T-CH | 3.4L / 207 OHV V6 12V "E,F" Chev. 92.00mm Bore 96-09

CHEVROLET, PONTIAC, BUICK, OLDSMOBILE

GM214C-CH | 3.5L / 214 OHV V6 12V "8" GM 94.00mm Bore 04-06

CHEVROLET

GM214T-CH | 3.5L / 214 OHV V6 12V "L" GM 94.00mm Bore 05-07

BUICK, CHEVROLET, PONTIAC

IS2835T/GM | 2.8L / 2835 OHV V6 12V "R" GM 89.00mm Bore 89-91

ISUZU

IS3137T/GM | 3.1L / 3137 OHV V6 12V "Z" GM 89.00mm Bore 91-94

ISUZU

Package Detail

Weight

0.4 lbs

Package Size

2.5x2x4.5"
